Annex
|
Operating wavelength |
l |
1310±25 |
1550±25 |
nm |
|
Insertion loss |
IL |
≤3.5 |
dB |
|
|
Beam splitting ratio |
-- |
48/52~52/48 |
dB |
|
|
Maximum input optical power |
Pmax |
≤200 |
mW |
|
|
Polarized crosstalk |
-- |
≤-30 |
dB |
|
|
Polarization extinction ratio |
PER |
≥60 |
dB |
|
|
Backward light reflection |
-- |
≤-50 |
dB |
|
|
Additional intensity modulation |
-- |
≤ 0.2% |
dB |
|
|
Optical fiber type |
-- |
PM or SM |
-- |
|
|
Diameter of pigtail fiber |
-- |
80/170 or 125/250 |
μm |
|
Electrical parameters
|
Parameter |
Symbol |
Min |
Typ |
Max |
Unit |
|
Half-wave voltage |
VΠ |
≤4.0 |
V |
||
|
Working frequency |
f |
0-300 |
MHz |
||
|
Voltage withstanding range of electrodes |
ZRF |
≤15 |
V |
||
|
Electrical interface |
|
3 PIN |
|||
Limit Condition
|
Parameter |
Symbol |
Unit |
Numerical value |
|
Operating temperature |
Top |
℃ |
-45 ~ +70 |
|
Storage temperature |
Tst |
℃ |
-55 ~ +85 |
|
Humidity |
RH |
% |
5 |
