parameters

sym

min

typ

max

unit

Optical parameters

Working wavelength

l

1064±20

nm

Insert loss

IL

-

6

8

dB

Optical return loss

ORL

-40

-45

-

dB

Switch extinction ratio @DC

ER@DC

48

50

-

dB

Optical fiber

Input

PM fiber 980 nm

Output

PM fiber 980 nm

Optical fiber interface

FC/PC、FC/APC or customized

Electrical parameters

Working bandwidth（-3dB）

S₂₁

6

-

GHz

Bandwidth fluctuation

DS₂₁

-

0.5

1

dB

Half-wave voltage Vpi

RF

Vπ@50kHz

-

4.5

5

V

Bias

Vπ@Bias

-

4.5

5

V

Electrical return loss

S₁₁

-

-12

-10

dB

Input impedance

RF

Z_RF

50

W

Bias

Z_BIAS

1 M

W

Electrical interface

SMA(f)
